Transmission Electron Microscopy (TEM) Analysis
| Parameter | Specification |
|---|---|
| Technique | Transmission Electron Microscopy (TEM) |
| Resolution | Sub-nanometer to atomic-scale |
| Accelerating Voltage | Typically 200 – 300 kV |
| Imaging Modes | Bright Field (BF), Dark Field (DF), HRTEM |
| Diffraction | Selected Area Electron Diffraction (SAED) |
| Elemental Analysis | EDS / EDX (optional) |
| Energy Loss Analysis | EELS (optional) |
| Sample Thickness | < 100 nm (electron transparent) |
| Sample Type | Thin films, nanoparticles, multilayers, interfaces |
| Sample Preparation | FIB lamella, ion milling, ultramicrotomy |
| Information Obtained | Crystal structure, lattice defects, interfaces, phase identification |
| Typical Use Cases | Semiconductor interfaces, oxide systems, advanced functional materials |
Payment. Secure payments via Bank Transfer, UPI, Credit/Debit Card, and approved Institutional PO. Flexible terms available for bulk and research orders.
Quality Assurance. All products are quality-checked, performance-validated, and sourced from verified manufacturers to ensure reliability and compliance with laboratory standards.
Description
Advanced Transmission Electron Microscopy (TEM)
Advanced transmission electron microscopy service for atomic- and nanometer-scale structural, crystallographic, and compositional analysis of materials. TEM enables direct visualization of interfaces, defects, and internal microstructure beyond the limits of surface-based techniques.
Key Applications
-
Interface and defect analysis
-
Semiconductor and thin-film characterization
-
Nanomaterial and particle structure evaluation
-
Failure analysis at nanometer scale
-
Advanced materials research and validation
Specifications
| Parameter | Specification |
|---|---|
| Technique | Transmission Electron Microscopy (TEM) |
| Resolution | Sub-nanometer to atomic-scale |
| Accelerating Voltage | Typically 200 – 300 kV |
| Imaging Modes | Bright Field (BF), Dark Field (DF), HRTEM |
| Diffraction | Selected Area Electron Diffraction (SAED) |
| Elemental Analysis | EDS / EDX (optional) |
| Energy Loss Analysis | EELS (optional) |
| Sample Thickness | < 100 nm (electron transparent) |
| Sample Type | Thin films, nanoparticles, multilayers, interfaces |
| Sample Preparation | FIB lamella, ion milling, ultramicrotomy |
| Information Obtained | Crystal structure, lattice defects, interfaces, phase identification |
| Typical Use Cases | Semiconductor interfaces, oxide systems, advanced functional materials |
Sample Preparation Support
-
Focused Ion Beam (FIB) lamella preparation
-
Cross-sectional and plan-view samples
-
Site-specific interface targeting
-
Preparation for multilayer and heterogeneous materials
-
(Sample preparation is critical for TEM data quality and is handled end-to-end.)
Deliverables
-
High-resolution TEM images
-
Diffraction patterns (SAED)
-
Elemental maps and line profiles (if requested)
-
Expert interpretation aligned with material behavior
Who Should Use This Service
-
Semiconductor R&D and failure analysis teams
-
Advanced materials and thin-film researchers
-
Industries requiring atomic-scale validation
-
Organizations dealing with interface-dominated materials
Important Note
TEM analysis requires electron-transparent samples.
Our team evaluates material suitability and recommends the appropriate preparation route prior to analysis.
