Description

The GHEXA-A22.0302 Naked Eye 3D Stereo Microscope is an innovative, eyepiece-free stereo microscope that delivers true three-dimensional viewing directly through a large observation window using naked-eye 3D technology—no eyepieces or head required. It features interchangeable objectives (standard 2×, 4×, 6×; optional 8×, 10×, 15×, and 6× super long working distance), a CMO parallel optical system for sharp, distortion-free imaging, a large track stand with 200 mm coarse focusing range, and built-in halogen or LED illumination (reflected light with separate control box for brightness adjustment). Available with multiple stand options including G-clamp, square base, double square base, universal boom arm, and a five-star mobile base with casters and lock for flexible positioning. This unique design provides an immersive, fatigue-free 3D experience ideal for prolonged inspection, teaching, assembly, and demonstration in laboratories, workshops, and educational settings.

Specifications

Key Applications & Uses

• Group demonstrations and teaching in schools, colleges, universities, and training centers—multiple users view the same 3D image simultaneously without eyepieces
• Prolonged inspection of electronic components, PCBs, solder joints, and small assemblies without eye strain
• Precision assembly, rework, and quality control in electronics manufacturing, jewelry, watchmaking, and dental labs
• Dissection, sample preparation, and 3D observation of biological specimens in botany, zoology, and entomology laboratories
• Surface examination of materials, fractures, coatings, and defects in industrial R&D, metallurgy, and quality assurance
• Interactive presentations, seminars, and workshops where observers need to point, discuss, or annotate directly on the sample
• Ergonomic, fatigue-free viewing during long-duration tasks in pharma packaging inspection, biotech sample handling, and forensic analysis

Why Choose from G-Hexa?

• Revolutionary naked-eye 3D viewing through a large window eliminates eyepiece discomfort and enables true group observation—no head alignment or interpupillary adjustment needed
• CMO parallel optical system provides high-resolution, distortion-free 3D images with excellent depth perception and large field of view
• Flexible objective selection (2×–15× standard & optional, including super LWD 6×) covers a wide range of working distances and detail levels
• Separate brightness-adjustable halogen/LED illumination control box ensures optimal contrast and reduces heat for sensitive samples
• Multiple stand configurations (G-clamp, square, double square, universal boom, mobile five-star base with casters & lock) adapt to bench, floor, or mobile workstation needs
• Tension-adjustable mobile base allows free movement and secure locking—perfect for shared labs, classrooms, or production lines
• Backed by G-Hexa’s expert technical support, 1-year warranty (extendable), calibration assistance, and dedicated after-sales service tailored for Indian educational institutions, research labs, and industrial users

Frequently Asked Questions (FAQs)

How does naked-eye 3D viewing work on the GHEXA-A22.0302? It uses advanced CMO parallel optics and a large observation window to project a true stereoscopic 3D image directly to the naked eye—no eyepieces or special glasses required. Multiple people can view simultaneously from different angles.

What magnifications are available? Standard objectives provide 2×, 4×, and 6×; optional 8×, 10×, 15×, and 6× super LWD objectives allow expansion to higher or lower magnifications with extended working distances.

Is illumination included and adjustable? Yes — built-in reflected LED (or optional halogen) with a separate control box for independent brightness adjustment, ensuring optimal lighting without overheating samples.

Which stand options are best for group teaching? The five-star mobile base with casters and lock offers the most flexibility for classroom movement; universal boom or double square stands suit fixed bench setups with large samples.

Can I attach a camera for documentation? The trinocular configuration supports C-mount adapters (optional); contact us for compatible cameras to capture or project the 3D view.

Is this microscope suitable for prolonged use? Absolutely — the eyepiece-free design and ergonomic viewing angle significantly reduce eye and neck strain, making it ideal for hours-long inspection or demonstration sessions.

What warranty and support does G-Hexa provide? 1-year standard warranty on parts and labor, with extendable options, preventive maintenance, and priority technical support from our Nashik-based team.

How can I get a quote or demo? Visit ghexa.com to submit an enquiry, specify your preferred stand/objective combination, or email us your requirements—we provide fast customized quotes and can arrange on-site demonstrations in Nashik, Pune, or across India.
