Description

The GHEXA-23.1501-T3 Continuous Zoom Stereo Microscope is a high-performance, trinocular stereo zoom microscope built for professional-grade inspection, research, and quality control tasks. It features a continuous zoom range of 0.8×–5.0× (zoom ratio 1:6.25) with click stops at 1×, 2×, 3×, and 4× for precise, repeatable settings, delivering standard magnification of 8×–50× with super wide-field WF10×/22 mm eyepieces (extendable to 4×–200× with optional auxiliary lenses and eyepieces). The Seidentopf trinocular head (360° rotatable) supports easy camera attachment, while the large square track stand (no built-in illumination) provides a stable platform with 100 mm coarse focusing range. Optional auxiliary lenses (0.5×, 0.7×, 2.0×) extend working distance up to 211 mm, and the A56.1522 60-LED ring light adds powerful reflected illumination when needed. This model offers exceptional depth perception, ergonomic comfort, and modular expandability for electronics, biology, materials science, and industrial applications.

Specifications

Key Applications & Uses

• Precision inspection and quality control of electronic PCBs, solder joints, micro-components, and semiconductor devices
• Biological sample dissection, preparation, and three-dimensional observation in botany, zoology, entomology, and microbiology laboratories
• Assembly, rework, and detailed examination in electronics manufacturing, jewelry, watchmaking, and dental labs
• Surface defect, fracture, coating, and texture analysis in materials science, metallurgy, and industrial R&D
• Routine quality assurance in pharma packaging inspection, biotech sample handling, textile/fiber analysis, and forensic evidence review
• Educational and training use in universities and technical institutes requiring stable, large-platform stereo viewing
• High-magnification tasks with optional ring light or auxiliary lenses for enhanced contrast on reflective or textured specimens

Why Choose from G-Hexa?

• Smooth 1:6.25 continuous zoom (0.8×–5.0×) with click stops at 1×, 2×, 3×, 4× for fast, reproducible magnification settings during repetitive inspections
• Super wide-field WF10×/22 mm eyepieces (≥23 mm field of view) with dual diopter adjustment provide immersive, strain-free viewing for long sessions
• Large square track stand with 100 mm coarse focus range offers rock-solid stability and ample workspace for big or heavy samples
• Trinocular head enables direct C-mount camera attachment for digital imaging, documentation, live display, or teaching purposes
• Optional auxiliary lenses (0.5×, 0.7×, 2.0×) extend working distance up to 211 mm and magnification to 200× for maximum flexibility
• Modular design supports add-on illumination (e.g., A56.1522 60-LED ring light) for shadow-free, high-contrast reflected lighting when needed
• Reliable Greenough optics, universal 110–220 V compatibility, and G-Hexa’s dedicated support including 1-year warranty, calibration guidance, and fast after-sales service tailored for Indian research, educational, and industrial labs

Frequently Asked Questions (FAQs)

What is the standard magnification range of the GHEXA-23.1501-T3? 8×–50× with the included WF10×/22 mm eyepieces and 0.8×–5.0× zoom body; optional eyepieces and auxiliary lenses extend it up to 4×–200×.

Does the track stand include built-in illumination? No — the big square track stand in this model has no integrated light; illumination is provided via optional accessories such as the A56.1522 60-LED ring light or alternative illuminated stands.

What working distance is available? Standard 115 mm; auxiliary lenses (0.5×, 0.7×, 2.0×) allow extension up to 211 mm for larger samples or tool manipulation.

Can I attach a camera for documentation or live viewing? Yes — the trinocular head is designed for easy C-mount adapter attachment to microscopy cameras for photo/video capture or real-time display.

What are the click stops on the zoom knob for? They provide precise, repeatable positions at 1×, 2×, 3×, and 4×, making it simple to switch back to specific magnifications during workflows.

Is additional illumination recommended? For most applications, yes — the optional A56.1522 60-LED ring light or other upper/bottom LED setups deliver uniform, adjustable lighting for reflective or low-contrast samples.

What warranty and support does G-Hexa provide? 1-year standard warranty on parts and labor, with extendable options, preventive maintenance, and priority technical support from our Nashik-based team.

How can I get a quote or customize the microscope? Submit an enquiry on ghexa.com specifying auxiliary lenses, eyepieces, ring light, or preferred illumination setup—we’ll provide a fast customized quote and can arrange demonstrations in Maharashtra or across India.
